Textile laminated conveyor belt for coal mine
Uses: Not only flame retardant, high strength, good groove formation, but also high interlayer adhesion strength, it will not produce delamination, deviation, etc. during use, suitable for the safe transportation of coal mine materials.
It is also suitable for high-speed transportation: the maximum belt speed can reach 8M/S, which provides protection for improving production efficiency. It has a good belt width retention rate and an independent warp and weft structure to ensure that the belt width will not become narrow during use.
It is also suitable for high-speed transportation: the maximum belt speed can reach 8M/S, which provides protection for improving production efficiency. It has a good belt width retention rate and an independent warp and weft structure to ensure that the belt width will not become narrow during use.
Ordering Consultation
Service Hotline:
|
Product Introduction
煤礦用織物疊層阻燃輸送帶產品為國內首創,采用MT830-2008《煤礦用織物疊層阻燃輸送帶》為產品出廠檢驗標準,產品質量、安全阻燃等各項性能不僅填補了國內煤礦用織物疊層阻燃輸送帶的空白,更達到國際領先水平,通過了中國石化聯合會組織的科技成果鑒定。
特性:
1、使用壽命長:平均屈撓壽命可達100萬次以上,在正常工況條件下,覆蓋膠磨損壽命可達1000-3000萬噸過煤量,是所有品種塑料整芯帶的3-5倍。2、耐寒性優良:在零下20°C使用條件下,整芯帶變硬變脆,而疊層織物阻燃輸送帶依然柔軟可用。
3、接頭強度高:鋼卡接頭強度約為原帶體強度80%(整芯帶50%),膠接接頭強度約為原帶體強度的90%,膠接接頭使用壽命幾乎等同帶體整體使用壽命。
4、帶體輕?。罕阌诿旱V井下重復使用。
產品結構:
產品以分層聚酯帆布疊加后為骨架層,覆以阻燃性能良好的粘合膠、覆蓋膠經硫化而成。
